>>  概述

myc-sam9g35 核心板是深圳市米尔科技有限公司推出,基于 atmel at91sam9g35 处理器的 arm9 核心板,该款产品属于 myc-sam9x5 系列核心板中的一款。

myc-sam9g35 核心板正面图:

myc-sam9g35 核心板

图1 myc-sam9g35 核心板

myc-sam9g35 核心板背面图:

myc-sam9g35 核心板背面图

图2 myc-sam9g35 核心板背面图

关于 myc-sam9g35 核心板软硬件资源,请查看 myc-sam9x5 系列核心板 中的详细介绍。


chip instruction


based on the arm926ej-s processor and running at 400mhz, the sam9g35 integrates advanced user interface and high-speed communication peripherals. it features an advanced graphics lcd controller with 4-layer overlay offering picture-in-picture, alpha-blending, scaling, rotation and color conversion and a 10-bit adc that supports 4- or 5-wire resistive touchscreen panels. multiple communication interfaces include a soft modem supporting exclusively the conexant smartdaa line driver, usb host and device and fs usb host with on-chip transceivers, 10/100 ethernet mac, two hs sdcard/sdio/mmc interfaces, usarts, spis, i2s and twis. 2 x 8 dma channels and dedicated dmas for the communication and interface peripherals ensure uninterrupted data transfers with minimal processor overhead. the external bus interface incorporates controllers offering support for 8-bank ddr2/lpddr, sdram/lpsdram, static memories, as well as specific circuitry for mlc/slc nand flash with integrated ecc up to 24 bits. the sam9g35 is available in a 217-ball bga package with 0.8mm ball pitch.


cpu logic diagram


key parameters for sam9g35


parameter

value

flashkbytes

0

pin count

217

max. operating frequency

400 mhz

cpu

arm926

hardware qtouch acquisition

no

max i/o pins

105

ext interrupts

105

usb transceiver

3

quadrature decoder channels

0

usb speed

hi-speed

usb interface

host, device

spi

2

twi (i2c)

3

uart

6

can

0

lin

4

ssc

1

ethernet

1

sd/emmc

2

segment lcd

0

graphic lcd

yes

video decoder

no

camera interface

no

adc channels

12

adc resolution (bits)

10

adc speed (ksps)

440

analog comparators

0

resistive touch screen

yes

dac channels

0

dac resolution (bits)

0

temp. sensor

no

crypto engine

no

sram (kbytes)

32

eeprom (bytes)

0

self program memory

no

external bus interface

1

dram memory

ddr2/lpddr, sdram/lpsdr

nand interface

yes

picopower

no

temp. range (deg c)

-40 to 85

i/o supply class

1.8/3.3

operating voltage (vcc)

0.9 to 1.1

fpu

no

mpu / mmu

no/yes

timers

6

output compare channels

6

input capture channels

6

pwm channels

4

32khz rtc

yes

calibrated rc oscillator

no
